Auto Feeding System Cnc 2d Wire Bending Machine
Advantages & Feature of 2d wire bending machine:
Brief description
The 2D CNC wire bending machine is a fully automatic machine for producing various two-dimensional die pressing parts. As long as the
parameters are set on the operating table, the ideal two-dimensional shape can be bended at one time without additional dies. The
line diameter range is suitable for 2.0-6.0 mm.
Processing wire, steel wire, stainless steel wire, non-ferrous wire (round, square, flat), bending, square, round, hexagonal,
elliptical irregular shape and various flat buttons, hooks.
ZD-2d-306 model 2d wire bending machine technical parameters:
Model | ZD-2D-206 |
Axis | 3 |
Wire diameter | 2—6mm iron wire |
wire-feeding wheel | 3 |
applicable wire | Round wire,flat bar, square wire (any material) |
Copy | 10000 datas,300 acts as a group |
Feeding speed max. | 22(m/min) |
Wire-feeding axis servo motor | 2.5kw |
Cutting axis servo motor | 1.0kw |
Angle-bending axis servo motor | 1.8kw |
Process | Lifting up and down for internal and outernal die Two-way bending |
Feeding accuracy | ±0.1mm |
Max. Bending speed | 800rpm/min,angle±180º |
Production capacity | 20-24 pieces/min,(200*200mm ,square) |
Operation system | 32 betain in Chinese and English (upload and download) |
voltage | 380V,50HZ/60HZ,3 Phases |
weight | 750kg |
dimension | 3000×950×1500mm |
Customer positive feedback
Company Profile
Our services of 2d wire bending machine:
1. Help you choose the most suitable 2d wire bending machine .
2. Making the machine according to your request.
3. Give you machine’s details for help you use the machine more better.
4. 2 years warranty
5. Free repair whole using life without extra charge.
Packaging and shipping
0
FAQ of 2d wire bending machine:
what is 2d wire bending machine Packaging?
Free fumigation safe Wood case package.
what is MOQ?
1set can be acceptable for trail order.
Over 3sets can have wholesale price. Welcome to join us as our sales agent in your market.
can we do OEM and ODM?
Can changing on design , color ,: acceptable(welcome)
develop on artwork and sketch : acceptable
4. what is your warranty?
Warranty 1 years
5.what time for delivery?
5-7 days for our own design.(motor:380v 50hz 3phases)
10-15 days for cusmoized model.
6.How do payment?
TT, 40-50% deposit ,balanced paid off before shippment.
We are a Chinese manufacturer specializing in the production of 2d wire forming machine , with many years of industry experience. We have our own independent research and development design team and production team, as well as a complete after-sales service system. We can provide customized services according to your needs. If you are interested in our products, please feel free to contact us at any time.
