2mm-6mm
greatcity
Greatcity 2d Wire Bending Machine Automatic
Advantages & Feature of Greatcity 2d Wire Bending Machine Automatic :
1. The error of full servo motor is smaller, the bending efficiency is higher, and the error is smaller than that of similar products of hydraulic press.
2. CNC operation is simpler and easier to learn than the same type of PLC products. Generally, the simple program can be edited by oneself within half an hour with elementary school education.
3. Because all the servo motors are used, there will be no hydraulic failure, the failure rate is lower, the scrubbing is more convenient, and the pollution caused by oil pollution will not occur.
2d wire bending machine Application field :
1)Auto Industry area
2)Metal wire industry
3)Display table and cargo shelf
4)Furniture and Kitchen
5)Hardware industry
6)Mattress, Sofa spring area
7)Architecture area
8)Hardware Artcraft
ZD-2d-306 model Greatcity 2d Wire Bending Machine Automatic technical parameters:
Model | ZD-2D-306 |
Axis | 3 |
Wire diameter | 3—6mm iron wire |
wire-feeding wheel | 3 |
applicable wire | Round wire,flat bar, square wire (any material) |
Copy | 10000 datas,300 acts as a group |
Feeding speed max. | 22(m/min) |
Wire-feeding axis servo motor | 2.6kw |
Cutting axis servo motor | 2.0kw |
Angle-bending axis servo motor | 2.0kw |
Process | Lifting up and down for internal and outernal die Two-way bending |
Feeding accuracy | ±0.1mm |
Max. Bending speed | 800rpm/min,angle±180º |
Production capacity | 20-24 pieces/min,(200*200mm ,square) |
Operation system | 32 betain in Chinese and English (upload and download) |
voltage | 380V,50HZ/60HZ,3 Phases |
weight | 800kg |
dimension | 2600×1000×1400 |
Our services of Greatcity 2d Wire Bending Machine Automatic :
1. Help you choose the most suitable 2d wire bending machine .
2. Making the machine according to your request.
3. Give you machines details for help you use the machine more better.
4. 2 years warranty
5. Free repair whole using life without extra charge.
FAQ of Greatcity 2d Wire Bending Machine Automatic:
what is 2d wire bending machine Packaging?
Free fumigation safe Wood case package.
what is MOQ?
1set can be acceptable for trail order.
Over 3sets can have wholesale price. Welcome to join us as our sales agent in your market.
can we do OEM and ODM?
Can changing on design , color ,: acceptable(welcome)
develop on artwork and sketch : acceptable
4. what is your warranty?
Warranty 1 years
5.what time for delivery?
5-7 days for our own design.(motor:380v 50hz 3phases)
10-15 days for cusmoized model.
6.How do payment?
TT, 40-50% deposit ,balanced paid off before shippment.
Any questions or requirements for Greatcity 2d Wire Bending Machine Automatic,welcome to contact me at any time
Xingtai Judu technology Co.,Ltd
Ms Kitty
Whatsapp / wechat: 008615512868421
