Prompt Shipment Zero Error 2d Wire Bending Machine Cnc Wire Forming Machine Tool with CE

CNC 2d Wire Bending Machine From China is to produce kinds of 2D wire forms expertly with high precision and fast speed. Adopts brand servo motor and screen display with top controller.
process diameter :
2-6mm soft wire , 2-4mm hard wire
Control system :
CNC programming system
Availability:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

  • ZD-2D-206

  • greatcity

  • 8463300000

2d wire bending machine wire forming machine cnc wire forming machine
Product Description

          Prompt Shipment Zero Error 2d Wire Bending Machine Cnc Wire Forming Machine Tool with CE


Advantages & Feature of CNC 2d Wire Bending Machine From China:


1. The error of full servo motor is smaller, the bending efficiency is higher, and the error is smaller than that of similar products of hydraulic press.

2. CNC operation is simpler and easier to learn than the same type of PLC products. Generally, the simple program can be edited by oneself within half an hour with elementary school education.

3. Because all the servo motors are used, there will be no hydraulic failure, the failure rate is lower, the scrubbing is more convenient, and the pollution caused by oil pollution will not occur.

2d wire bending machine Application field :

1)Auto Industry area
2)Metal wire industry

3)Display table and cargo shelf
4)Furniture and Kitchen

5)Hardware industry
6)Mattress, Sofa spring area
7)Architecture area
8)Hardware Artcraft


ZD-2d-206 model CNC 2d Wire Bending Machine technical parameters:


Model

ZD-2D-206

 Axis

3 or 4 axis or 5 axis

           Wire diameter

2—6mm iron wire

wire-feeding wheel

3

 applicable wire

Round wire,flat bar, square wire

(any material)

Copy

10000 datas,300 acts as a group

Feeding speed max.

22(m/min)

Wire-feeding axis servo motor

2.6kw

Cutting axis servo motor

2.0kw

Angle-bending axis servo motor

2.6kw

          Process

Lifting up and down for internal and outernal die

Two-way bending

Feeding accuracy

±0.1mm

Max. Bending speed

800rpm/min,angle±180º

Production capacity

20-24 pieces/min,(200*200mm ,square)

        Operation system

              32 betain in Chinese and English

(upload and download)

voltage

380V,50HZ/60HZ,3 Phases

weight

800kg

dimension

2600×1000×1400


2d wire bending machine - judutechnologywire bending machine - judutechnologycnc wire bending machine - judutechnologybending samples of wire bending machine - judutechnology新弯线机_03


Our services of CNC 2d Wire Bending Machine From China:


1. Help you choose the most suitable 2d wire bending machine .

2. Making the machine according to your request.

3. Give you machines details  for help you use the machine more better.

4. 2 years warranty

5. Free repair whole using life without extra charge.


FAQ of CNC 2d Wire Bending Machine From China:


  1. what is 2d wire bending machine Packaging?
     Free fumigation safe Wood case package.


  2. what is MOQ?
    1set can be acceptable for trail order.
    Over 3sets can have wholesale price. Welcome to join us as our sales agent in your market.


  3. can we do OEM and ODM?

      Can changing on design , color ,: acceptable(welcome)
      develop on artwork and sketch : acceptable


   4. what is your warranty?

     Warranty 1 years


    5.what time for delivery?
      5-7 days for our own design.(motor:380v 50hz 3phases)
      10-15 days for cusmoized model.


    6.How do payment?
      TT, 40-50% as deposit ,balanced paid off before shippment.
